TPS54350PWPG4

TPS54350PWPG4, synchronous buck PWM converter, TSSOP, 100 mΩ, 4.5A

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.60~0.80 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.60~0.80

PartNumber:: TPS54350PWPG4

Brand:: Texas Instruments - TI | Pack: TSSOP | D/C: 08+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Wendy's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-06-04

From Other Seller

Part Number:TPS54350PWPG4
US $0.60 - 0.80
HEF4093BT

US $0.15 - 1.20 / Piece
(0) Remove
2DI75D-050A

US $16.00 - 30.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The TPS54350PWPG4 is a medium output current synchronous buck PWM converter with an integrated high side MOSFET and a gate driver for an optional low side external MOSFET. Features of the TPS54350PWPG4 include a high performance voltage error amplifier that enables maximum performance under transient conditions and flexibility in choosing the output filter inductors and capacitors. The TPS54350PWPG4 has an under-voltage-lockout circuit to prevent start-up until the input voltage reaches 4.5 V; an internal slow-start circuit to limit in-rush currents; and a power good output to indicate valid output conditions.

Parametrics

TPS54350PWPG4 absolute maximum ratings: (1)Input voltage range, VI: VIN: -0.3 V to 21.5 V, VSENSE: -0.3 V to 8.0 V, UVLO: -0.3 V to 8.0 V; (2)Output voltage range, VO: LSG: -0.3 to 8.5 V, RT: -0.3 to 4.0 V, SYNC: -0.3 to 4.0 V, PWRGD: -0.3 to 6.0 V, COMP: -0.3 to 4.0 V; (3)Source current, IO: PH: -1.5 V to 22 V, PH: Internally Limited (A), LSG (Steady State Current) 10 mA, COMP, VBIAS: 3 mA; (4)Voltage differential: AGND to PGND: ±0.3 V; (5)Operating virtual junction temperature range, TJ: -40℃ to +150℃; (6)Storage temperature, Tstg: -65℃ to +150℃; (7)Lead temperature 1,6 mm (1/16 inch) from case for 10 seconds: 260℃.

Features

TPS54350PWPG4 features: (1)100 mΩ, 4.5-A Peak MOSFET Switch for High Efficiency at 3-A Continuous Output Current; (2)Uses External Lowside MOSFET or Diode; (3)Output Voltage Adjustable Down to 0.891 V With 1% Accuracy; (4)Synchronizes to External Clock; (5)180 Out of Phase Synchronization; (6)Wide PWM Frequency-Fixed 250 kHz, 500 kHz or Adjustable 250 kHz to 700 kHz; (7)Internal Slow Start; (8)Load Protected by Peak Current Limit and Thermal Shutdown.
