WJLXT908LE.A4 865811

WJLXT908LE.A4 865811, Universal 10BASE-T and AUI Transceiver, 64-LQFP, 3.3V

Rated 5 Rating 5 | reviews | Write a review

Price:: US $2.00~2.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $2.00~2.50

PartNumber:: WJLXT908LE.A4 865811

Brand:: Cortina Systems, Inc. - Cortina | Pack: QFP | D/C: 08+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Wendy's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-05-18

From Other Seller

Part Number:WJLXT908LE.A4 865811
US $2.00 - 2.50
ad7716ap

US $1.13 - 1.13 / Piece
(0) Remove
PIC16F917-I/P(PIC16F917-IP)

US $1.60 - 2.20 / Piece
(0) Remove
Quantity:

piece

Product Summary

The WJLXT908LE.A4 865811 Universal 10BASE-T and AUI Transceiver is designed for IEEE 802.3 physical layer applications. It provides all the active circuitry to interface most standard 802.3 controllers to either the 10BASE-T media or Attachment Unit Interface (AUI). In addition to standard 10 Mbps Ethernet, the WJLXT908LE.A4 865811 also supports full-duplex operation at 20 Mbps. The WJLXT908LE.A4 865811 is fabricated with an advanced CMOS process and requires only a single 3.3V power supply. The WJLXT908LE.A4 865811 is ideal for: (1)Access devices (DSL, Cable Modems, and Set-top Boxes); (2)Routers/ Bridges/ Switches/ Hubs; (3)Telecom Backplane; (4)USB to Ethernet Converters.

Parametrics

WJLXT908LE.A4 865811 absolute maximum ratings: (1)Supply voltage VCC: -0.3 to 6 V; (2)Storage temperature TSTG: -65 to +150℃.

Features

WJLXT908LE.A4 865811 features: (1)Improved Filters - Simplifies FCC Compliance; (2)Integrated Manchester Encoder/Decoder; (3)10BASE-T compliant Transceiver; (4)AUI Transceiver; (5)Supports Standard and Full-Duplex Ethernet; (6)Four LED Drivers; (7)AUI/RJ-45 Loopback; (8)Automatic/Manual AUI/RJ-45 Selection; (9)Automatic Polarity Correction; (10)SQE Disable/Enable function; (11)Power Down Mode with tri-stated outputs; (12)Four loopback modes; (13)Single 3.3V operation; (14)Available in 64-pin LQFP and 44-pin PLCC package; (15)Commercial (0 to +70℃) and Extended (-40 to +85℃) temperature range.
