Product Summary

The E28F016SV-70-120 16-Mbit FlashFile memory is a revolutionary architecture which is the ideal choice for designing embedded direct-execute code and mass storage data/file flash memory systems. With innovative capabilities, low-power operation, user-selectable VPP voltage and high read/program performance, the E28F016SV-70-120 enables the design of truly mobile, high-performance personal computing and communications products. The E28F016SV-70-120 is the highest density, highest performance nonvolatile read/program solution for solid-state storage applications.

Parametrics

E28F016SV-70-120 absolute maximum ratings: (1)Temperature Under Bias : 0°C to +80°C; (2)Storage Temperature : –65°C to +125°C; (3)TA Operating Temperature, Commercial: 0 to 70 °C; (4)VCC VCC with Respect to GND: –0.2 to 7.0 V; (5)VPP VPP Supply Voltage with Respect to GND: –0.2 to 14.0 V; (6)V Voltage on Any Pin (except VCC,VPP)with Respect to GND: –0.5 to VCC + 0.5 V; (7)I Current into Any Non-Supply Pin: ± 30 mA; (8)IOUT Output Short Circuit Current: 100 mA.

Features

E28F016SV-70-120 features: (1)65 ns Access Time; (2)1 MillioErase Cycles per Block; (3)30.8 MB/sec Burst Write Transfer Rate; (4)0.48 MB/sec Sustainable Write Transfer Rate; (5)Configurable x8 or x16 Operation; (6)56-Lead TSOP and SSOP Type I Packages 2 μA Typical Deep Power-Down; (7)32 Independently Lockable Blocks; (8)State-of-the-Art 0.6 μm ETOX IV Flash Technology.

Diagrams

E28F016SV-70-120 dimension
