AD5346BRUZ

AD5346BRUZ, TSSOP, octal 8-bit DAC, 1.4 mA, 2.5 V to 5.5 V, 20 ns

Rated 5 Rating 5 | reviews | Write a review

Price:: US $8.00~8.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $8.00~8.50

PartNumber:: AD5346BRUZ

Brand:: Analog Devices - ADI | Pack: TSSOP | D/C: 08+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Wendy's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-06-05

From Other Seller

Part Number:AD5346BRUZ
US $8.00 - 8.50
FM31256-G

US $2.40 - 4.20 / Piece
(0) Remove
HT46R47

US $0.35 - 1.50 / Piece
(0) Remove
Quantity:

piece

Product Summary

The AD5346BRUZ is an octal 8-bit DAC, operating from a 2.5 V to 5.5 V supply. The AD5346BRUZ incorporates an on-chip output buffer that can drive the output to both supply rails, and also allow a choice of buffered or unbuffered reference input. The AD5346BRUZ has a parallel interface. CS selects the device and data is loaded into the input registers on the rising edge of WR. A readback feature allows the internal DAC registers to be read back through the digital port.The AD5346BRUZ is ideal for: (1)Portable battery-powered instruments; (2)Digital gain and offset adjustment; (3)Programmable voltage and current sources; (4)Optical networking; (5)Automatic test equipment; (6)Mobile communications; (7)Programmable attenuators; (8)Industrial process control.

Parametrics

AD5346BRUZ absolute maximum ratings: (1)VDD to GND: –0.3 V to +7 V; (2)Digital Input Voltage to GND: –0.3 V to VDD + 0.3 V; (3)Digital Output Voltage to GND: –0.3 V to VDD + 0.3 V; (4)Reference Input Voltage to GND: –0.3 V to VDD + 0.3 V; (5)VOUT to GND: –0.3 V to VDD + 0.3 V; (6)Operating Temperature Range: Industrial (B Version): –40℃ to +105℃; (7)Storage Temperature Range: –65℃ to +150℃; (8)Junction Temperature: 150℃.

Features

AD5346BRUZ features: (1)octal 8-bit DAC; (2)Low power operation: 1.4 mA (max) @ 3.6 V; (3)Power-down to 120 nA @ 3 V, 400 nA @ 5 V; (4)Guaranteed monotonic by design over all codes; (5)Rail-to-rail output range: 0 V to VREF or 0 V to 2 × VREF; (6)Power-on reset to 0 V; (7)Simultaneous update of DAC outputs via LDAC pin; (8)Asynchronous CLR facility; (9)Readback; (10)Buffered/unbuffered reference inputs; (11)20 ns WR time; (12)38-lead TSSOP/6 mm × 6 mm 40-lead LFCSP packaging; (13)Temperature range: –40℃ to +105℃.
